INSIZE UTM-E50 multi-function electronic tensile and compression machine

Technical specifications:

• Maximum test force: 50 kN
• Accuracy level: Level 0.5
• Test force range: 0.2% - 100%FS
• Test force accuracy: ±0.5% of displayed value
• Test force resolution: 1 /300000 of maximum test force
• Strain measuring range: 0.2% - 100%FS
• Strain display accuracy: ±0.5% of displayed value< /li>
• Deformation resolution: 1/300000 of maximum deformation
• Deformation range over large range: 10-800 mm
• Deformation accuracy over large range: ±1% of displayed value
• Deformation resolution over large range: 8 μm
• Displacement range accuracy: ±0.5% of value display
• Displacement range resolution: 0.025 μm
• Control force speed adjustment range: 0.005 - 5% FS/s
• Accuracy Control force speed accuracy:
  • ±2% of set value (ratio < 0.5% FS/s)
  • ±0.5% of set value (ratio > 0.5% FS/s)
• Strain ratio adjustment range: 0.2% - 100% FS
• Strain ratio accuracy:
  • ±2% of set value (rate < 0.5% FS/s)
  • ±0.5% of set value (rate > 0.5% FS/s)< /li>
• Beam shift speed adjustment range: 0.001 - 500mm/min
• Beam shift speed accuracy:
  < li>±1% of set value (rate < 0.5mm/min)
  • ±0.2% of set value (rate > 0.5mm/min)
• Distance between jaws: 970 mm
• Compression range: 700 mm
• Working range: 440 mm
• Power supply: 220 V, 50 Hz, 0.4-1 kW
• Dimensions: 820x620x1880 mm
• Weight: 350 kg
